| Brand Name: | Kitefiy |
| Model Number: | AF-10 |
| MOQ: | 1 |
| Payment Terms: | T/T |
The AF-10 Tethered Suspended Light is a highly portable, all-in-one outdoor illumination system that a single operator can effortlessly carry, complete with integrated energy storage. Designed for rapid deployment in field operations, emergency response, and remote area lighting, it combines a tethered airborne light source with a compact ground unit, delivering powerful, sustained overhead illumination with zero setup complexity.
Specifications
Product Name: AF-10
Electrical Interface: Aviation connector
Total System Weight: 3,350 g
Airborne Unit Weight: 241 g
Ground Unit Weight: 2,550 g
Airborne Unit Dimensions (Unfolded): 273 × 273 × 61 mm
Airborne Unit Dimensions (Folded): 117 × 117 × 127 mm
Ground Unit Dimensions: 250 × 173 × 165 mm
Airborne Lighting Rated Power: ≤100 W
Arm Light Brightness: 16,000 lm
Illuminated Area: 1,300 m² (with 31x as illumination boundary)
Ground Flashlight Power: 20 W
Lighting Modes: Ambient light mode; Red-blue strobe mode; SOS mode
Arm Indicator Light: Dual-color (red & green) LED
Hovering Accuracy: ±10 m
Flight Altitude: ±10 m
Wind Resistance: 8 m/s
Positioning Technology: RTK (BDS + GPS + Galileo + GLONASS + QZSS)
Operating Temperature: -10°C to +40°C
Operating Altitude: 3,000 m
Control Mode: APP / Ground unit dual-mode control
Built-in Battery: 2,500 mAh, 14.8 V
Power Adapter: Input: 100–240 V~ 50/60 Hz, 5.0 A Max; Output: 48.0 V, 5.0 A, 240 W
