| Brand Name: | Kitefly |
| Model Number: | WF-1000S60-8K |
| MOQ: | 1~5unit |
| Price: | negotiable |
| Delivery Time: | 1~4week |
| Payment Terms: | T/T,L/C,Western Union |
|
Model |
WF-1000S60-8K |
|
Compatible Ground Stations |
delivering 800-1000Vdc input for 1000V-class tethered UAV systems; confirm system matching before order |
|
Input Voltage |
800-1000Vdc (for 1000V-class tethered power architecture) |
|
Output Voltage |
60Vdc rated; 57-60.5Vdc output range |
|
Output Current |
134A rated, 150A maximum |
|
Rated Power |
8KW |
|
Efficiency |
>=97% |
|
Voltage Regulation Accuracy |
+/-1% |
|
Source / Load Regulation |
+/-1% / +/-1% |
|
Output Ripple & Noise |
<=+/-2%Vo (20MHz bandwidth limit) |
|
Dynamic Response Recovery |
<=2ms |
|
Power-On Delay |
<=5s at rated input |
|
IP Rating |
IP54 |
|
Operating Temperature |
-40C to +50C (self-contained air cooling) |
|
Storage Temperature |
-40C to +80C |
|
Relative Humidity |
<=95% RH, no condensation (40C +/-2C) |
|
Maximum Altitude |
0-2000m |
|
Dimensions |
187 x 185 x 70mm shell size (+/-1mm) |
|
Weight |
About 2.2-2.3kg |
|
MTBF |
>=100,000 hours |
|
Warranty |
1 Year |
|
Availability |
Build-to-order or limited stock; confirm lead time with sales |
