| Brand Name: | Kitefly |
| Model Number: | WF-750S50-6K |
| MOQ: | 1 |
| Payment Terms: | T/T |
|
Model |
WF-750S50-6K |
|
Compatible Ground Stations |
Any Kitefly tethered ground station with >=6000W output at 600-750Vdc; consult team for system matching |
|
Input Voltage |
600-750Vdc (rated input: 720Vdc) |
|
Output Voltage |
50 +/-0.5Vdc (rated; range 45-50.5Vdc) |
|
Output Current |
120A rated |
|
Rated Power |
6000W |
|
Peak Power |
7000W |
|
Efficiency |
>=96% (Vin=720Vdc, >50% load) |
|
Voltage Regulation Accuracy |
+/-1% |
|
Output Ripple & Noise |
<=700mVp-p (20MHz bandwidth, rated load) |
|
IP Rating |
IP65; no water accumulation on top |
|
Operating Temperature |
-20C to +40C (continuous 6kW operation) |
|
Storage Temperature |
-40C to +80C |
|
Relative Humidity |
<=95% (no condensation at 40C +/-2C) |
|
Maximum Altitude |
3000m |
|
Cooling Method |
Self-contained fan cooling |
|
Dimensions |
248 x 107 x 75 +/-1mm |
|
Weight |
<=1.4kg |
|
MTBF |
>=100,000 hours |
|
Warranty / Availability |
1 Year; In Stock (2-3 weeks if out of stock) |
